Linnox ULE Burners Deliver Ultra Low Emissions and Uniform Heat. The Eclipse Linnox ULE burner is designed for use in any direct or indirect fired air heating application requiring state-of-the-art burner technology. Where excellent heat distribution, temperature uniformity, best in class low emissions, and simple robust controls are the decision points in product selection and specification, the Linnox ULE is the industry standard. Linnox burner operation is based on a high excess air pre-mix combustion that keeps flame temperatures low while burner geometry establishes an internal recirculation flame pattern. This allows for very low emissions at a high turndown rate (10:1) while maintaining extremely stable combustion. Specifically, the emissions in the undiluted flue gasses are less than 15 ppm NOx at nominal input, establishing the Linnox burner as the lowest NOx burner of its kind. The Linnox Tee ULE configuration option provides multiple rows of burner modules to increase burner inputs up to 45 MM Btu/h. Eclipse designs custom Linnox ULE systems to meet your specific application requirements.
Features & Benefits:
- High performance and ultra low emissions
- Excellent heat distribution and temperature uniformity
- Design supports wide range of inputs/unit of length
- Up to 10:1 turn down
- NOx emissions are less than 15 ppm @ 3% O2
- CO emissions are less than 100 ppm @ 3% O2
- Robust ratio regulator controlled gas/air ratio
